    山东模具钢的温度如何正确的掌握?

    来源:https://www.jnqhmj.com/ 日期:2021-01-22 发布人:admin


    现在,模具钢的制作变得越来越复杂,因此,创造适宜条件以如何确定模具温度变得越来越难。除了简单零件以外,模塑温度控制系统通常会是一个折衷方案。因此,下列用我个人的理解和视角给出对山东模具钢的温度正确掌握的一些方法。
    Nowadays, the manufacture of die steel becomes more and more complex, so it is more and more difficult to create suitable conditions to determine the die temperature. In addition to simple parts, molding temperature control system is usually a compromise. Therefore, the following with my personal understanding and perspective to give the correct grasp of the temperature of Shandong die steel some methods.
    1.在模具钢设计阶段必须要考虑对被加工零件外型的温度控制。
    1. In the design stage of die steel, the temperature control of the machined parts must be considered.
    山东模具钢
    2.如果设计低注射量、大模塑尺寸模具时,重要的是要考虑传热性要好。如果可能的话,请使用加压水作为控制温度介质。使用耐高压高温的有韧性的管道和歧管。
    2. When designing the mold with low injection volume and large molding size, it is important to consider better heat transfer performance. If possible, use pressurized water as the temperature control medium. Use high pressure and high temperature resistant ductile pipes and manifolds.
    3.设计流体流过模具和进料管的截面尺寸时要留有余量。不要使用接头,否则这将对由模温控制的流体流动造成严重障碍。
    3. Allowance should be left when designing the cross-section size of the fluid flowing through the die and feed pipe. Do not use the joint, otherwise it will cause serious obstacles to the fluid flow controlled by the mold temperature.
    4.给出与模具相匹配的控温设备性能的详细说明。模具制造商给出的数据表中应提供关于流速的一些必要的数字。
    4. Give a detailed description of the performance of the temperature control equipment matched with the mold. The data sheet given by the mould manufacturer shall provide some necessary figures about the flow rate.
    5.在模具和机器模板搭接处请使用绝缘板。对动模和定模分别使用不同的温控系统,在任何一侧面和中心,请使用隔离的温控系统,这样可使模塑过程中有不同的启动温度。
    5. Please use insulating board at the joint of mould and machine formwork. Different temperature control systems are used for the moving mold and the fixed mold respectively. In any side and center, please use the isolated temperature control system, so that there are different starting temperatures in the molding process.
    6.不同的温控系统电路应串联,不能并联。如果电路并联,电阻的差异将引起温控介质的容积流速不同,从而会比在电路串联情况下发生更大的温度变化。只有在串联电路连接在模具入口和出口温差变化小于5°C时其操作才良好。
    6. Different temperature control system circuits should be in series, not in parallel. If the circuits are connected in parallel, the difference of resistance will cause the volume flow velocity of temperature control medium to be different, which will lead to greater temperature change than in the case of series connection. The operation of the series circuit is good only when the temperature difference between the inlet and outlet of the die is less than 5 ° C.
    模具钢温度的确定要测量许多点,而不是单点或一面的温度。然后可根据设定的控温标准进行修正。将模具温度调整至适当值。不同原料的一览表中都给出了建议的模具温度。这些建议通常都是考虑了高表面光洁度、机械性能、收缩性及加工周期等因素间的优异配置而给出来的。
    To determine the temperature of die steel, many points should be measured instead of single point or one side. Then it can be corrected according to the set temperature control standard. Adjust the mold temperature to an appropriate value. The recommended mold temperature is given in the list of different raw materials. These suggestions are usually given considering the excellent configuration of factors such as high surface finish, mechanical properties, shrinkage and processing cycle.
