H13 hardness of material after heat treatment(H13 steel composition)



　　目录



　　catalogue



　　h13模具钢如何热处理硬度才能达到HRC58



　　How to heat treat H13 die steel to achieve hrc58 hardness



　　h13硬度是多少



　　What is the hardness of H13



　　h13热处理温度多少



　　H13 what is the heat treatment temperature



　　H13用于温挤压模，其热处理规范和硬度要求是多少



　　H13 is used for warm extrusion die.What are the heat treatment specifications and hardness requirements



　　Q1：h13模具钢如何热处理硬度才能达到HRC58



　　Q1:how can the heat treatment hardness of H13 die steel reach hrc58



　　H13属于热作模具钢，主要考虑其高温下韧性和强度的匹配较好。不知朋友要用H13做什么用，为什么要把硬度设成这么高，但可以肯定的是，如果H13只淬火而不回火，硬度可能会达到你的要求，但于室温工作时，如果工作温度升高，其硬度必然下降，况且不回火的H13很脆的，很容易裂掉。所以我认为你的选材本身就有问题。



　　H13 is a hot working die steel,mainly considering its good matching of toughness and strength at high temperature.I don't know what my friends want to do with H13 and why they want to set the hardness so high,but it is certain that if H13 is only quenched without tempering,the hardness may meet your requirements,but it is limited to working at room temperature.If the working temperature increases,its hardness will inevitably decrease.Moreover,H13 without tempering is very brittle and easy to crack.So I think your material selection itself has a problem.



　　h13材料热处理多少硬度(H13钢成分)Q2：h13硬度是多少



　　H13 material heat treatment hardness(H13 steel composition)Q2:H13 hardness



　　H13硬度：退火：245～205HB，淬火：≥50HRC。H13属于热作模具钢，是在碳工钢的基础上加入合金元素而形成的钢种，执行标准GB/T1299—2014。统一数字代号T23353;



　　H13 hardness:annealing:245~205hb,quenching:≥50HRC.H13 belongs to hot working die steel,which is a kind of steel formed by adding alloy elements on the basis of carbon work steel.It implements the standard GB/t1299-2014.Unified digital code t23353;



　　牌号4Cr5MoSiV1。在中温下的综合性能好，淬透性高（在空气中即能淬硬），热处理变形率较低，其性能及使用寿命高于3Cr2W8V。可用于模锻锤锻模、铝合金压铸模、热挤压模具、高速精锻模具及锻造压力机模具等。



　　Brand:4Cr5MoSiV1.It has good comprehensive performance at medium temperature,high hardenability(it can be hardened in air),low heat treatment deformation rate,and its performance and service life are higher than 3Cr2W8V.It can be used for die forging hammer forging die,aluminum alloy die casting die,hot extrusion die,high-speed precision forging die and forging press die,etc.



　　Q3：h13热处理温度多少



　　Q3:H13 what is the heat treatment temperature



　　淬火规范：温度1020--1050度，冷却介质：油或空气，硬度HRC：56--58。回火规范：温度560--580度，冷却：空冷，回火硬度HRC：47--49。通常采用两次回火，第二次回火温度应比次低20度。



　　Quenching specification:temperature 1020-1050℃,cooling medium:oil or air,hardness HRC:56-58.Tempering specification:temperature 560-580℃,cooling:air cooling,tempering hardness HRC:47-49.Generally,two tempering shall be adopted,and the temperature of the second tempering shall be 20℃lower than that of the first tempering.
